SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10016
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 500842 CABLE -KP RF NHA
010 515048 . HOUSING 1
020 514196 . COVER 1
030 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
040 087996 . SCREW TORX 4
050 528144 . PCB ASSEMBLY FOR CABLE -KP_CP 1
060 514164 . KNOB 10.5X3.7 1
070 549391 . INSERT BLACK, 10 PCS. 1
080 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
090 538737 . CABLE COPPER 0.33M
6.3MM JACK PLUG
1
100 538738 . CABLE COPPER 0.33MM
5.25MM JACK PLUG
1
-110 528106 . LABEL 1
ZZ120 515830 . FOLDER BOX, 150X40X170 1
ZZ130 085161 . LABEL, 89X97.6 1
- ITEM NOT ILLUSTRATED
Oct 30/08
