SENNHEISER ELECTRONIC GMBH & CO. KG
COMPONENT MAINTENANCE MANUAL
HMEC 26-SERIES
Page 10020
Mar 13/13
23-41-48
FIG. ITEM PART NUMBER AIRLINE
PART NO.
NOMENCLATURE EFF
CODE
UNITS
PER
ASSY
-001 500852 CABLE -CP RF NHA
010 515048 . HOUSING 1
020 514196 . COVER 1
030 549394 . OPTICAL WAVEGUIDE, 10 PCS. 1
040 087996 . LENS SCREW M2X8 4
050 523331 . PCB ASSEMBLY FOR CABLE-KP_CP 1
060 514164 . KNOB 10.5X3.7 1
070 549391 . INSERT BLACK, 10 PCS. 2
080 538741 . CABLE COPPER 1.54M
(SEE FIG. 17 FOR DET.)
1
090 538747 . CABLE 0.33M 1
-100 528106 . LABEL 1
ZZ110 515830 . FOLDER BOX, 150X40X170 1
ZZ120 085161 . LABEL, 89X97.6 1
- ITEM NOT ILLUSTRATED
