EW-D ASA antenna splitter
209
Connecting rod antennas
▷ Mount the antennas to the BNC sockets ANT RF IN A and
ANT RF IN B.
▷ Align the antennas in a V-shape in order to ensure the best
possible reception.
Information on antenna amplifiers and cable
lengths
The following table shows which cable lengths require the use
of the EW-D AB antenna amplifier as well as the maximum
recommended cable lengths.
Frequency variants of the EW-D AB: „EW-D AB antenna
booster“
