SENS MicroGenius S2/S4 Technical Manual
5
2 MODEL NUMBER BREAKOUT
S
4
-
C
1
0
-
H
0
0
0
0
0
0
0
A
B
C
D
E
F
G
H
I
J
K
L
M
Field
Parameter
Code
Value
A
Product Family
S
MicroGenius S
B
Enclosure
2
S2 chassis
4
S4 chassis
C
Output
and Protection
Options
A
Single output, no breakers
B
Single output, AC and DC breakers (S4 only)
C
Single output, AC/DC breakers with supplemental surge (S4 only)
D
Multiple output, single ground, no breakers
E
Multiple output, single ground, AC breaker (S4 only)
F
Multiple output, single ground, AC breaker, surge (S4 only)
D
Communications
0
J1939 and Modbus RS-485
1
J1939, Modbus TCP/IP, native SENSbus USB
2
J1939 and Modbus RS-485 with RJ-45 to terminal block adapter
3
J1939, Modbus TCP/IP, USB, & RJ45 to terminal block adapter
E
Configuration
0
Standard
R
19in rack mount ears (S4 only)
T
23in rack mount ears (S4 only)
F
Output A Code
X
See output code table
G
Output A Redundancy
X
See redundancy code table
H
Output B Code
X
See output code table
I
Output B Redundancy
X
See redundancy code table
J
Output C Code
X
See output code table
K
Output C Redundancy
X
See redundancy code table
L
Output D Code
X
See output code table
M
Output D Redundancy
X
See redundancy code table
OUTPUT CODE
REDUNDANCY CODE
CODE
VOLTAGE
CURRENT
CASE
CODE
REDUNDANCY
0
N/A
N/A
N/A
0
N + 0
A
12 / 24V
15A
S4
1
N + 1
B
12 / 24V
20A
S2
2
N + 2
D
12 / 24V
30A
S2/S4
F
12 / 24V
45A
S4
H
12 / 24V
60A
S4
