Address High
Address Low
Name
Description
Units
Scale
Duration
754 0x2F2 755 0x2F3
Output D Default Output
Commissioning VPC
Commissioning VPC V/Cell 32768
756 0x2F4 757 0x2F5
Output D Default Output
Commissioning Duration
Commissioning Duration Hr 3600
758 0x2F6 759 0x2F7
Output D Default Output
Commissioning A
Commissioning Amps A 32768
760 0x2F8 761 0x2F9
Output D Default Output
Rated Power
Output Rated Power W 32768
762 0x2FA 763 0x2FB
Output D Default Output
Rated Current
Output Rated Current A 32768
764 0x2FC 765 0x2FD
Output D Periodic Boost
Duration
Periodic Boost Duration Bits 3600
766 0x2FE 767 0x2FF
Channel D Min Allowed
Voltage Setting
Min Allowed Voltage Setting V/Cell 32768
11.3. Status Definition
Value
Name Description
Decimal
Hex
0
0x00
Startup
Turning on or in bootloader
1
0x01
Idle
Charger is "off"
2
0x02
Boost
Boost Charge Mode
3
0x03
Slave
Following another unit's commands
4
0x04
Float
Float Charge Mode
5
0x05
Low Battery Charge
Charging but output is below low battery threshold
6
0x06
AC Not Working
AC not detected or out of range for operation
7
0x07
Invalid Settings
The charger is locked out because settings are invalid
8
0x08
Reverse Polarity
The charger is off due to a reverse polarity condition
9
0x09
Reserved For Future Use
Reserved for Future Use
10 0x0A Low Battery Error
Charger was not able to bring up a low battery in the
required time
11
0x0B
Over Current Protection
Charger has detected an over current condition
12
0x0C
Charger Fail
Charger has detected a failure and has locked itself off
13 0x0D SENSbus Error
Charger could not find a valid SENSbus address and has
shutdown
14
0x0E
HELIX Eco
HELIX Eco-Float Charge Mode
15
0x0F
HELIX Refresh
HELIX Refresh Charge Mode
16
0x10
Periodic Boost
Scheduled or Forced Time controlled Boost
17
0x11
Battery Check
Scheduled or Forced Battery Check Routine
18
0x12
Commission Charge
Timed Commission Charge
11.4. Alarm Bit Definition
Bit Address
Name Description
Decimal
Hex
0
0x00
Alarm AC Fail
Charger does not have usable AC input
1
0x01
Alarm High DC
Charger output exceeds alarm threshold
2
0x02
Alarm Low DC
Charger output below alarm threshold
3
0x03
Alarm Charger Fail
Charger not operating because of an internal failure
4
0x04
Alarm Over Voltage Shutdown
Charger disabled by selective overvoltage shutdown
5
0x05
Alarm Reverse Polarity
Charger disabled because battery polarity is reversed
6
0x06
Alarm Low Cranking
Low cranking voltage event has been detected
7 0x07 Alarm Incompatible Battery
Charger disabled because it does not match battery (12V
vs. 24V)
