SENS MicroGenius S2/S4 Technical Manual
53
Address High
Address Low
Name
Description
Units
Scale
678 0x2A6 679 0x2A7
Output D Battery Check
Interval
Interval between scheduled
automatic battery checks
Sec 1
680 0x2A8 681 0x2A9
Output D Number of
Chargers
Number of chargers detected on
SENSbus, 0 - 30
Num 1
682 0x2AA 683 0x2AB Output D Redundancy Level
Number of redundant output
chargers
Num 1
684 0x2AC 685 0x2AD Output D Extended Status
Current state of alarm/comms circuit
board (see section 11.5)
bit 1
704
0x2C0
705
0x2C1
Output D Maximum Power
Maximum rated power
V/Cell
32768
706 0x2C2 707 0x2C3
Output D Maximum
Voltage
Maximum rated voltage in x.xx V V/Cell 32768
708 0x2C4 709 0x2C5
Output D Maximum
Current
Maximum rated current in x.xxA A 32768
710 0x2C6 711 0x2C7
Output D Program Float
Setting
Float Cell Voltage used in Program
Mode
V/Cell 32768
712 0x2C8 713 0x2C9
Output D Program Boost
Setting
Boost Cell Voltage used in Program
Mode
V/Cell 32768
714 0x2CA 715 0x2CB Output D Program Mode
Mode callouts for Program Mode
setting (battery type… etc.)
Custom 1
716 0x2CC 717 0x2CD
Output D Program Cell
Count
Number of cells set in Program Mode Cells 32768
718 0x2CE 719 0x2CF
Output D Program Temp
comp slope
In 0.xx°C per output volt x -1 °C/V 32768
720 0x2D0 721 0x2D1 Output D Low DC Program
Alarm setpoint for low DC (used for
Program Mode setting)
V/Cell 32768
722 0x2D2 723 0x2D3
Output D Low Crank
Program
Alarm setpoint for low Crank (used
for Program Mode setting)
V/Cell 32768
724 0x2D4 725 0x2D5
Output D Low Current
Program
Alarm setpoint for low Current(used
for Program Mode setting)
A 32768
728 0x2D8 729 0x2D9 Output D High DC Program
Alarm setpoint for high DC (used for
Program Mode setting)
V/Cell 32768
730 0x2DA 731 0x2DB Output D OVSD Program
Alarm setpoint for OVSD (used for
Program Mode setting)
V/Cell 32768
732 0x2DC 733 0x2DD
Output D Batt Discharge
Program
Alarm setpoint for Batt Discharge
(used for Program Mode setting)
V/Cell 32768
734 0x2DE 735 0x2DF
Output D Batt End
Discharge Program
Alarm setpoint for End Discharge
(used for Program Mode setting)
V/Cell 32768
736 0x2E0 737 0x2E1
Output D Program Boost
Time Limit
Boost time limit (used for Program
Mode setting)
Hr 3600
738 0x2E2 739 0x2E3
Output D Current Limit
Setting
Current Limit setpoint in % of output
current as a 10 bit value
% Rated
A
32768
740 0x2E4 741 0x2E5
Output D Default Output
Helix Float Time
Helix Float Time Hr 3600
742 0x2E6 743 0x2E7
Output D Default Output
Helix Refresh Time
Helix Refresh Time Hr 3600
744 0x2E8 745 0x2E9
Output D Default Output
Helix Eco Time
Helix Eco Time Hr 3600
746 0x2EA 747 0x2EB
Output D Default Output
Periodic Boost Time
Interval between scheduled Periodic
Boost
Days 86400
748 0x2EC 749 0x2ED
Output D Battery Check
Voltage Setting
Battery check failure threshold V/Cell 32768
750 0x2EE 751 0x2EF
Output D Battery Check
Interval
Interval between scheduled
automatic battery checks
Days 86400
752
0x2F0
753
0x2F1
Output D Battery Check
Duration of battery check
Min
60
