SENS MicroGenius S2/S4 Technical Manual
52
Address High
Address Low
Name
Description
Units
Scale
Voltage Setting
606 0x25E 607 0x25F
Output C Battery Check
Interval
Interval between scheduled
automatic battery checks
Days 86400
608 0x260 609 0x261
Output C Battery Check
Duration
Duration of battery check Min 60
610 0x262 611 0x263
Output C Default Output
Commissioning VPC
Commissioning VPC V/Cell 32768
612 0x264 613 0x265
Output C Default Output
Commissioning Duration
Commissioning Duration Hr 3600
614 0x266 615 0x267
Output C Default Output
Commissioning A
Commissioning Amps A 32768
616 0x268 617 0x269
Output C Default Output
Rated Power
Output Rated Power W 32768
618 0x26A 619 0x26B
Output C Default Output
Rated Current
Output Rated Current A 32768
620 0x26C 621 0x26D
Output C Periodic Boost
Duration
Periodic Boost Duration Bits 3600
622 0x26E 623 0x26F
Channel C Min Allowed
Voltage Setting
Min Allowed Voltage Setting V/Cell 32768
640 0x280 641 0x281 Output D Status
Current State of the charger (see
section 11.3)
Bits 1
642
0x282
643
0x283
Output D Alarms
Alarm status bits (see section 11.4)
Bits
1
644 0x284 645 0x285 Output D Voltage
Voltage currently being supplied by
the charger to the battery
V 32768
646 0x286 647 0x287 Output D Output Current
Current currently being supplied by
the charger to the battery
A 32768
648 0x288 649 0x289 Output D Power Output
Power currently being supplied by
the charger
W 32768
650 0x28A 651 0x28B
Output D Factory Float
Setting
Float Cell Voltage set at Factory V/cell 32768
652 0x28C 653 0x28D
Output D Factory Boost
Setting
Boost Cell Voltage set at Factory V/cell 32768
654 0x28E 655 0x28F Output D Remote Temp
Remote temp sense temperature in
0.0°C
°C 32768
656 0x290 657 0x291 Output D Internal Temp
Ambient air temperature near
charger input connectors (tp 1)
°C 32768
658 0x292 659 0x293
Output D Boost Elapsed
Time
Boost time Sec 1
660 0x294 661 0x295
Output D Periodic Boost
Period
Interval between periodic boost
events (0 = disabled)
Sec 1
662 0x296 663 0x297
Output D AC Line
Frequency
AC Line Frequency Hz 10
664
0x298
665
0x299
Output D AC Line Voltage 1
AC Line 1 Voltage
V
32768
666
0x29A
667
0x29B
Output D AC Line Current 1
AC Line 1 Current
A
32768
668 0x29C 669 0x29D Output D AC Line Voltage 2
AC Line 2 Voltage (Not applicable to
single phase chargers)
V 32768
670 0x29E 671 0x29F Output D AC Line Current 2
AC Line 2 Current (Not applicable to
single phase chargers)
A 32768
672 0x2A0 673 0x2A1 Output D AC Line Voltage 3
AC Line 3 Voltage (Not applicable to
single phase chargers)
V 32768
674 0x2A2 675 0x2A3 Output D AC Line Current 3
AC Line 3 Current (Not applicable to
single phase chargers)
A 32768
676 0x2A4 677 0x2A5
Output D Battery Check
Duration
Duration of battery check Sec 1
