SENS MicroGenius S2/S4 Technical Manual
51
Address High
Address Low
Name
Description
Units
Scale
528 0x210 529 0x211 Output C AC Line Voltage 3
AC Line 3 Voltage (Not applicable to
single phase chargers)
V 32768
530 0x212 531 0x213 Output C AC Line Current 3
AC Line 3 Current (Not applicable to
single phase chargers)
A 32768
532 0x214 533 0x215
Output C Battery Check
Duration
Duration of battery check Sec 1
534 0x216 535 0x217
Output C Battery Check
Interval
Interval between scheduled
automatic battery checks
Sec 1
536 0x218 537 0x219
Output C Number of
Chargers
Number of chargers detected on
SENSbus, 0 - 30
Num 1
538 0x21A 539 0x21B Output C Redundancy Level
Number of redundant output
chargers
Num 1
540 0x21C 541 0x21D Output C Extended Status
Current state of alarm/comms circuit
board (see section 11.5)
bit 1
560
0x230
561
0x231
Output C Maximum Power
Maximum rated power
V/Cell
32768
562
0x232
563
0x233
Output C Maximum Voltage
Maximum rated voltage in x.xx V
V/Cell
32768
564
0x234
565
0x235
Output C Maximum Current
Maximum rated current in x.xxA
A
32768
566 0x236 567 0x237
Output C Program Float
Setting
Float Cell Voltage used in Program
Mode
V/Cell 32768
568 0x238 569 0x239
Output C Program Boost
Setting
Boost Cell Voltage used in Program
Mode
V/Cell 32768
570 0x23A 571 0x23B Output C Program Mode
Mode callouts for Program Mode
setting (battery type… etc.)
Custom 1
572 0x23C 573 0x23D
Output C Program Cell
Count
Number of cells set in Program Mode Cells 32768
574 0x23E 575 0x23F
Output C Program Temp
comp slope
In 0.xx°C per output volt x -1 °C/V 32768
576 0x240 577 0x241 Output C Low DC Program
Alarm setpoint for low DC (used for
Program Mode setting)
V/Cell 32768
578 0x242 579 0x243
Output C Low Crank
Program
Alarm setpoint for low Crank (used
for Program Mode setting)
V/Cell 32768
580 0x244 581 0x245
Output C Low Current
Program
Alarm setpoint for low Current(used
for Program Mode setting)
A 32768
584 0x248 585 0x249 Output C High DC Program
Alarm setpoint for high DC (used for
Program Mode setting)
V/Cell 32768
586 0x24A 587 0x24B Output C OVSD Program
Alarm setpoint for OVSD (used for
Program Mode setting)
V/Cell 32768
588 0x24C 589 0x24D
Output C Batt Discharge
Program
Alarm setpoint for Batt Discharge
(used for Program Mode setting)
V/Cell 32768
590 0x24E 591 0x24F
Output C Batt End
Discharge Program
Alarm setpoint for End Discharge
(used for Program Mode setting)
V/Cell 32768
592 0x250 593 0x251
Output C Program Boost
Time Limit
Boost time limit (used for Program
Mode setting)
Hr 3600
594 0x252 595 0x253
Output C Current Limit
Setting
Current Limit setpoint in % of output
current as a 10 bit value
% Rated
A
32768
596 0x254 597 0x255
Output C Default Output
Helix Float Time
Helix Float Time Hr 3600
598 0x256 599 0x257
Output C Default Output
Helix Refresh Time
Helix Refresh Time Hr 3600
600 0x258 601 0x259
Output C Default Output
Helix Eco Time
Helix Eco Time Hr 3600
602 0x25A 603 0x25B
Output C Default Output
Periodic Boost Time
Interval between scheduled Periodic
Boost
Days 86400
604
0x25C
605
0x25D
Output C Battery Check
Battery check failure threshold
V/Cell
32768
