Sens MicroGenius S2 - Page 50

SENS MicroGenius S2/S4 Technical Manual
50
Address High
Address Low
Name
Description
Units
Scale
Helix Refresh Time
456 0x1C8 457 0x1C9
Output B Default Output
Helix Eco Time
Helix Eco Time Hr 3600
458 0x1CA 459 0x1CB
Output B Default Output
Periodic Boost Time
Interval between scheduled Periodic
Boost
Days 86400
460 0x1CC 461 0x1CD
Output B Battery Check
Voltage Setting
Battery check failure threshold V/Cell 32768
462 0x1CE 463 0x1CF
Output B Battery Check
Interval
Interval between scheduled
automatic battery checks
Days 86400
464 0x1D0 465 0x1D1
Output B Battery Check
Duration
Duration of battery check Min 60
466 0x1D2 467 0x1D3
Output B Default Output
Commissioning VPC
Commissioning VPC V/Cell 32768
468 0x1D4 469 0x1D5
Output B Default Output
Commissioning Duration
Commissioning Duration Hr 3600
470 0x1D6 471 0x1D7
Output B Default Output
Commissioning A
Commissioning Amps A 32768
472 0x1D8 473 0x1D9
Output B Default Output
Rated Power
Output Rated Power W 32768
474 0x1DA 475 0x1DB
Output B Default Output
Rated Current
Output Rated Current A 32768
476 0x1DC 477 0x1DD
Output B Periodic Boost
Duration
Periodic Boost Duration Bits 3600
478 0x1DE 479 0x1DF
Channel B Min Allowed
Voltage Setting
Min Allowed Voltage Setting V/Cell 32768
496 0x1F0 497 0x1F1 Output C Status
Current State of the charger (see
section 11.3)
Bits 1
498
0x1F2
499
0x1F3
Output C Alarms
Alarm status bits (see section 11.4)
Bits
1
500 0x1F4 501 0x1F5 Output C Voltage
Voltage currently being supplied by
the charger to the battery
V 32768
502 0x1F6 503 0x1F7 Output C Output Current
Current currently being supplied by
the charger to the battery
A 32768
504 0x1F8 505 0x1F9 Output C Power Output
Power currently being supplied by
the charger
W 32768
506 0x1FA 507 0x1FB
Output C Factory Float
Setting
Float Cell Voltage set at Factory V/cell 32768
508 0x1FC 509 0x1FD
Output C Factory Boost
Setting
Boost Cell Voltage set at Factory V/cell 32768
510 0x1FE 511 0x1FF Output C Remote Temp
Remote temp sense temperature in
0.0°C
°C 32768
512 0x200 513 0x201 Output C Internal Temp
Ambient air temperature near
charger input connectors (tp 1)
°C 32768
514 0x202 515 0x203
Output C Boost Elapsed
Time
Boost time Sec 1
516 0x204 517 0x205
Output C Periodic Boost
Period
Interval between periodic boost
events (0 = disabled)
Sec 1
518 0x206 519 0x207
Output C AC Line
Frequency
AC Line Frequency Hz 10
520
0x208
521
0x209
Output C AC Line Voltage 1
AC Line 1 Voltage
V
32768
522
0x20A
523
0x20B
Output C AC Line Current 1
AC Line 1 Current
A
32768
524 0x20C 525 0x20D Output C AC Line Voltage 2
AC Line 2 Voltage (Not applicable to
single phase chargers)
V 32768
526 0x20E 527 0x20F Output C AC Line Current 2
AC Line 2 Current (Not applicable to
single phase chargers)
A 32768
