SENS MicroGenius S2/S4 Technical Manual
49
Address High
Address Low
Name
Description
Units
Scale
376
0x178
377
0x179
Output B AC Line Voltage 1
AC Line 1 Voltage
V
32768
378
0x17A
379
0x17B
Output B AC Line Current 1
AC Line 1 Current
A
32768
380 0x17C 381 0x17D Output B AC Line Voltage 2
AC Line 2 Voltage (Not applicable to
single phase chargers)
V 32768
382 0x17E 383 0x17F Output B AC Line Current 2
AC Line 2 Current (Not applicable to
single phase chargers)
A 32768
384 0x180 385 0x181 Output B AC Line Voltage 3
AC Line 3 Voltage (Not applicable to
single phase chargers)
V 32768
386 0x182 387 0x183 Output B AC Line Current 3
AC Line 3 Current (Not applicable to
single phase chargers)
A 32768
388 0x184 389 0x185
Output B Battery Check
Duration
Duration of battery check Sec 1
390 0x186 391 0x187
Output B Battery Check
Interval
Interval between scheduled
automatic battery checks
Sec 1
392 0x188 393 0x189
Output B Number of
Chargers
Number of chargers detected on
SENSbus, 0 - 30
Num 1
394 0x18A 395 0x18B Output B Redundancy Level
Number of redundant output
chargers
Num 1
396 0x18C 397 0x18D Output B Extended Status
Current state of alarm/comms circuit
board (see section 11.5)
bit 1
416
0x1A0
417
0x1A1
Output B Maximum Power
Maximum rated power
V/Cell
32768
418
0x1A2
419
0x1A3
Output B Maximum Voltage
Maximum rated voltage in x.xx V
V/Cell
32768
420
0x1A4
421
0x1A5
Output B Maximum Current
Maximum rated current in x.xxA
A
32768
422 0x1A6 423 0x1A7
Output B Program Float
Setting
Float Cell Voltage used in Program
Mode
V/Cell 32768
424 0x1A8 425 0x1A9
Output B Program Boost
Setting
Boost Cell Voltage used in Program
Mode
V/Cell 32768
426 0x1AA 427 0x1AB Output B Program Mode
Mode callouts for Program Mode
setting (battery type… etc.)
Custom 1
428 0x1AC 429 0x1AD
Output B Program Cell
Count
Number of cells set in Program Mode Cells 32768
430 0x1AE 431 0x1AF
Output B Program Temp
comp slope
In 0.xx°C per output volt x -1 °C/V 32768
432 0x1B0 433 0x1B1 Output B Low DC Program
Alarm setpoint for low DC (used for
Program Mode setting)
V/Cell 32768
434 0x1B2 435 0x1B3
Output B Low Crank
Program
Alarm setpoint for low Crank (used
for Program Mode setting)
V/Cell 32768
436 0x1B4 437 0x1B5
Output B Low Current
Program
Alarm setpoint for low Current(used
for Program Mode setting)
A 32768
440 0x1B8 441 0x1B9 Output B High DC Program
Alarm setpoint for high DC (used for
Program Mode setting)
V/Cell 32768
442 0x1BA 443 0x1BB Output B OVSD Program
Alarm setpoint for OVSD (used for
Program Mode setting)
V/Cell 32768
444 0x1BC 445 0x1BD
Output B Batt Discharge
Program
Alarm setpoint for Batt Discharge
(used for Program Mode setting)
V/Cell 32768
446 0x1BE 447 0x1BF
Output B Batt End
Discharge Program
Alarm setpoint for End Discharge
(used for Program Mode setting)
V/Cell 32768
448 0x1C0 449 0x1C1
Output B Program Boost
Time Limit
Boost time limit (used for Program
Mode setting)
Hr 3600
450 0x1C2 451 0x1C3
Output B Current Limit
Setting
Current Limit setpoint in % of output
current as a 10 bit value
% Rated
A
32768
452 0x1C4 453 0x1C5
Output B Default Output
Helix Float Time
Helix Float Time Hr 3600
454
0x1C6
455
0x1C7
Output B Default Output
Helix Refresh Time
Hr
3600
