SENS MicroGenius S2/S4 Technical Manual
48
Address High
Address Low
Name
Description
Units
Scale
Time Limit
Mode setting)
306 0x132 307 0x133
Output A Current Limit
Setting
Current Limit setpoint in % of output
current as a 10 bit value
% Rated
A
32768
308 0x134 309 0x135
Output A Default Output
Helix Float Time
Helix Float Time Hr 3600
310 0x136 311 0x137
Output A Default Output
Helix Refresh Time
Helix Refresh Time Hr 3600
312 0x138 313 0x139
Output A Default Output
Helix Eco Time
Helix Eco Time Hr 3600
314 0x13A 315 0x13B
Output A Default Output
Periodic Boost Time
Interval between scheduled Periodic
Boost
Days 86400
316 0x13C 317 0x13D
Output A Battery Check
Voltage Setting
Battery check failure threshold V/Cell 32768
318 0x13E 319 0x13F
Output A Battery Check
Interval
Interval between scheduled
automatic battery checks
Days 86400
320 0x140 321 0x141
Output A Battery Check
Duration
Duration of battery check Min 60
322 0x142 323 0x143
Output A Default Output
Commissioning VPC
Commissioning VPC V/Cell 32768
324 0x144 325 0x145
Output A Default Output
Commissioning Duration
Commissioning Duration Hr 3600
326 0x146 327 0x147
Output A Default Output
Commissioning A
Commissioning Amps A 32768
328 0x148 329 0x149
Output A Default Output
Rated Power
Output Rated Power W 32768
330 0x14A 331 0x14B
Output A Default Output
Rated Current
Output Rated Current A 32768
332 0x14C 333 0x14D
Output A Periodic Boost
Duration
Periodic Boost Duration Bits 3600
334 0x14E 335 0x14F
Channel A Min Allowed
Voltage Setting
Min Allowed Voltage Setting V/Cell 32768
352 0x160 353 0x161 Output B Status
Current State of the charger (see
section 11.3)
Bits 1
354
0x162
355
0x163
Output B Alarms
Alarm status bits (see section 11.4)
Bits
1
356 0x164 357 0x165 Output B Voltage
Voltage currently being supplied by
the charger to the battery
V 32768
358 0x166 359 0x167 Output B Output Current
Current currently being supplied by
the charger to the battery
A 32768
360 0x168 361 0x169 Output B Power Output
Power currently being supplied by
the charger
W 32768
362 0x16A 363 0x16B
Output B Factory Float
Setting
Float Cell Voltage set at Factory V/cell 32768
364 0x16C 365 0x16D
Output B Factory Boost
Setting
Boost Cell Voltage set at Factory V/cell 32768
366 0x16E 367 0x16F Output B Remote Temp
Remote temp sense temperature in
0.0°C
°C 32768
368 0x170 369 0x171 Output B Internal Temp
Ambient air temperature near
charger input connectors (tp 1)
°C 32768
370 0x172 371 0x173
Output B Boost Elapsed
Time
Boost time Sec 1
372 0x174 373 0x175
Output B Periodic Boost
Period
Interval between periodic boost
events (0 = disabled)
Sec 1
374 0x176 375 0x177
Output B AC Line
Frequency
AC Line Frequency Hz 10
