SENS MicroGenius S2/S4 Technical Manual
47
Address High
Address Low
Name
Description
Units
Scale
228 0x0E4 229 0x0E5
Output A Periodic Boost
Period
Interval between periodic boost
events (0 = disabled)
Sec 1
230 0x0E6 231 0x0E7
Output A AC Line
Frequency
AC Line Frequency Hz 10
232
0x0E8
233
0x0E9
Output A AC Line Voltage 1
AC Line 1 Voltage
V
32768
234
0x0EA
235
0x0EB
Output A AC Line Current 1
AC Line 1 Current
A
32768
236 0x0EC 237 0x0ED Output A AC Line Voltage 2
AC Line 2 Voltage (Not applicable to
single phase chargers)
V 32768
238 0x0EE 239 0x0EF Output A AC Line Current 2
AC Line 2 Current (Not applicable to
single phase chargers)
A 32768
240 0x0F0 241 0x0F1 Output A AC Line Voltage 3
AC Line 3 Voltage (Not applicable to
single phase chargers)
V 32768
242 0x0F2 243 0x0F3 Output A AC Line Current 3
AC Line 3 Current (Not applicable to
single phase chargers)
A 32768
244 0x0F4 245 0x0F5
Output A Battery Check
Duration
Duration of battery check Sec 1
246 0x0F6 247 0x0F7
Output A Battery Check
Interval
Interval between scheduled
automatic battery checks
Sec 1
248 0x0F8 249 0x0F9
Output A Number of
Chargers
Number of chargers detected on
SENSbus, 0 - 30
Num 1
250 0x0FA 251 0x0FB Output A Redundancy Level
Number of redundant output
chargers
Num 1
252 0x0FC 253 0x0FD Output A Extended Status
Current state of alarm/comms circuit
board (see section 11.5)
bit 1
272
0x110
273
0x111
Output A Maximum Power
Maximum rated power
V/Cell
32768
274 0x112 275 0x113
Output A Maximum
Voltage
Maximum rated voltage in x.xx V V/Cell 32768
276 0x114 277 0x115
Output A Maximum
Current
Maximum rated current in x.xxA A 32768
278 0x116 279 0x117
Output A Program Float
Setting
Float Cell Voltage used in Program
Mode
V/Cell 32768
280 0x118 281 0x119
Output A Program Boost
Setting
Boost Cell Voltage used in Program
Mode
V/Cell 32768
282 0x11A 283 0x11B Output A Program Mode
Mode callouts for Program Mode
setting (battery type… etc.)
Custom 1
284 0x11C 285 0x11D
Output A Program Cell
Count
Number of cells set in Program Mode Cells 32768
286 0x11E 287 0x11F
Output A Program Temp
comp slope
In 0.xx°C per output volt x -1 °C/V 32768
288 0x120 289 0x121 Output A Low DC Program
Alarm setpoint for low DC (used for
Program Mode setting)
V/Cell 32768
290 0x122 291 0x123
Output A Low Crank
Program
Alarm setpoint for low Crank (used
for Program Mode setting)
V/Cell 32768
292 0x124 293 0x125
Output A Low Current
Program
Alarm setpoint for low Current(used
for Program Mode setting)
A 32768
296 0x128 297 0x129 Output A High DC Program
Alarm setpoint for high DC (used for
Program Mode setting)
V/Cell 32768
298 0x12A 299 0x12B Output A OVSD Program
Alarm setpoint for OVSD (used for
Program Mode setting)
V/Cell 32768
300 0x12C 301 0x12D
Output A Batt Discharge
Program
Alarm setpoint for Batt Discharge
(used for Program Mode setting)
V/Cell 32768
302 0x12E 303 0x12F
Output A Batt End
Discharge Program
Alarm setpoint for End Discharge
(used for Program Mode setting)
V/Cell 32768
304
0x130
305
0x131
Output A Program Boost
Boost time limit (used for Program
Hr
3600
