SENS MicroGenius S2/S4 Technical Manual
46
Address High
Address Low
Name
Description
Units
Scale
Discharge Program
(used for Program Mode setting)
158 0x09E 159 0x09F
Default Output Batt End
Discharge Program
Alarm setpoint for End Discharge
(used for Program Mode setting)
V/Cell 32768
160 0x0A0 161 0x0A1
Default Output Program
Boost Time Limit
Boost time limit (used for Program
Mode setting)
Hr 3600
162 0x0A2 163 0x0A3
Default Output Current
Limit Setting
Current Limit setpoint in % of output
current as a 10 bit value
% Rated
A
32768
164 0x0A4 165 0x0A5
Default Output Helix Float
Time
Helix Float Time Hr 3600
166 0x0A6 167 0x0A7
Default Output Helix
Refresh Time
Helix Refresh Time Hr 3600
168 0x0A8 169 0x0A9
Default Output Helix Eco
Time
Helix Eco Time Hr 3600
170 0x0AA 171 0x0AB
Default Output Periodic
Boost Time
Interval between scheduled Periodic
Boost
Days 86400
172 0x0AC 173 0x0AD
Default Output Battery
Check Voltage Setting
Battery check failure threshold V/Cell 32768
174 0x0AE 175 0x0AF
Default Output Battery
Check Interval
Interval between scheduled
automatic battery checks
Days 86400
176 0x0B0 177 0x0B1
Default Output Battery
Check Duration
Duration of battery check Min 60
178 0x0B2 179 0x0B3
Default Output
Commissioning VPC
Commissioning VPC V/Cell 32768
180 0x0B4 181 0x0B5
Default Output
Commissioning Duration
Commissioning Duration Hr 3600
182 0x0B6 183 0x0B7
Default Output
Commissioning A
Commissioning Amps A 32768
184 0x0B8 185 0x0B9
Default Output Rated
Power
Output Rated Power W 32768
186 0x0BA 187 0x0BB
Default Output Rated
Current
Output Rated Current A 32768
188 0x0BC 189 0x0BD
Default Output Periodic
Boost Duration
Periodic Boost Duration Bits 3600
190 0x0BE 191 0x0BF
Default Output Min
Allowed Voltage Setting
Min Allowed Voltage Setting V/Cell 32768
208 0x0D0 209 0x0D1 Output A Status
Current State of the charger (see
section 11.3)
Bits 1
210
0x0D2
211
0x0D3
Output A Alarms
Alarm status bits (see section 11.4)
Bits
1
212 0x0D4 213 0x0D5 Output A Voltage
Voltage currently being supplied by
the charger to the battery
V 32768
214 0x0D6 215 0x0D7 Output A Output Current
Current currently being supplied by
the charger to the battery
A 32768
216 0x0D8 217 0x0D9 Output A Power Output
Power currently being supplied by
the charger
W 32768
218 0x0DA 219 0x0DB
Output A Factory Float
Setting
Float Cell Voltage set at Factory V/cell 32768
220 0x0DC 221 0x0DD
Output A Factory Boost
Setting
Boost Cell Voltage set at Factory V/cell 32768
222 0x0DE 223 0x0DF Output A Remote Temp
Remote temp sense temperature in
0.0°C
°C 32768
224 0x0E0 225 0x0E1 Output A Internal Temp
Ambient air temperature near
charger input connectors (tp 1)
°C 32768
226 0x0E2 227 0x0E3
Output A Boost Elapsed
Time
Boost time Sec 1
