SENS MicroGenius S2/S4 Technical Manual
45
Address High
Address Low
Name
Description
Units
Scale
84 0x054 85 0x055
Default Output Periodic
Boost Period
Interval between periodic boost
events (0 = disabled)
Sec 1
86 0x056 87 0x057
Default Output AC Line
Frequency
AC Line Frequency Hz 10
88 0x058 89 0x059
Default Output AC Line
Voltage 1
AC Line 1 Voltage V 32768
90 0x05A 91 0x05B
Default Output AC Line
Current 1
AC Line 1 Current A 32768
92 0x05C 93 0x05D
Default Output AC Line
Voltage 2
AC Line 2 Voltage (Not applicable to
single phase chargers)
V 32768
94 0x05E 95 0x05F
Default Output AC Line
Current 2
AC Line 2 Current (Not applicable to
single phase chargers)
A 32768
96 0x060 97 0x061
Default Output AC Line
Voltage 3
AC Line 3 Voltage (Not applicable to
single phase chargers)
V 32768
98 0x062 99 0x063
Default Output AC Line
Current 3
AC Line 3 Current (Not applicable to
single phase chargers)
A 32768
100 0x064 101 0x065
Default Output Battery
Check Duration
Duration of battery check Sec 1
102 0x066 103 0x067
Default Output Battery
Check Interval
Interval between scheduled
automatic battery checks
Sec 1
104 0x068 105 0x069
Default Output Number of
Chargers
Number of chargers detected on
SENSbus, 0 - 30
Num 1
106 0x06A 107 0x06B
Default Output Redundancy
Level
Number of redundant output
chargers
Num 1
108 0x06C 109 0x06D
Default Output Extended
Status
Current state of alarm/comms circuit
board (see Extended Status Bit
Definition)
bit 1
128 0x080 129 0x081
Default Output Maximum
Power
Maximum rated power V/Cell 32768
130 0x082 131 0x083
Default Output Maximum
Voltage
Maximum rated voltage in x.xx V V/Cell 32768
132 0x084 133 0x085
Default Output Maximum
Current
Maximum rated current in x.xx A A 32768
134 0x086 135 0x087
Default Output Program
Float Setting
Float Cell Voltage used in Program
Mode
V/Cell 32768
136 0x088 137 0x089
Default Output Program
Boost Setting
Boost Cell Voltage used in Program
Mode
V/Cell 32768
138 0x08A 139 0x08B
Default Output Program
Mode
Mode callouts for Program Mode
setting (battery type… etc.)
Custom 1
140 0x08C 141 0x08D
Default Output Program
Cell Count
Number of cells set in Program Mode Cells 32768
142 0x08E 143 0x08F
Default Output Program
Temp comp slope
In 0.xx°C per output volt x -1 °C/V 32768
144 0x090 145 0x091
Default Output Low DC
Program
Alarm setpoint for low DC (used for
Program Mode setting)
V/Cell 32768
146 0x092 147 0x093
Default Output Low Crank
Program
Alarm setpoint for low Crank (used
for Program Mode setting)
V/Cell 32768
148 0x094 149 0x095
Default Output Low Current
Program
Alarm setpoint for low Current(used
for Program Mode setting)
A 32768
152 0x098 153 0x099
Default Output High DC
Program
Alarm setpoint for high DC (used for
Program Mode setting)
V/Cell 32768
154 0x09A 155 0x09B
Default Output OVSD
Program
Alarm setpoint for OVSD (used for
Program Mode setting)
V/Cell 32768
156
0x09C
157
0x09D
Default Output Batt
Alarm setpoint for Batt Discharge
V/Cell
32768
