SENS MicroGenius S2/S4 Technical Manual
56
Bit Address
Name Description
Decimal
Hex
17
0x11
Three Phase Input
Charger has three phase input
18
0x12
Battery Temperature Valid
Have valid remote temperature sensor reading
19
0x13
Scheduled Equalize Enabled
Scheduled boost charge cycles enabled
20 0x14
Scheduled Battery Check
Enabled
Scheduled battery check cycles enabled
21
0x15
UI Passive
UI access mode is passive (no keypad)
22
0x16
OBS UI Hidden Mode
Obsolete, reads false (Off, 0)
23
0x17
UI Monitor Mode
UI access mode is monitor only (no adjustments)
24
0x18
UI Normal Mode
UI access mode is normal (standard adjustments)
25 0x19 UI Advanced Mode
UI access mode is advanced (all adjustments, including
battery type and system configuration)
26 0x1A UI Access Code Unlocked
Unlocked by UI security code (can change UI access mode
and security code settings)
27
0x1B
Spare Bit 27
Not used, reads false (Off, 0)
28
0x1C
Spare Bit 28
Not used, reads false (Off, 0)
29
0x1D
Spare Bit 29
Not used, reads false (Off, 0)
30
0x1E
Multiple Outputs
More than one output is present
31 0x1F System Display Board
Display board monitors all units on SENSbus (not just those
in same unit)
11.6. Writable Control Flags (Coils)
Single coil writes: 0xFF00 for ON, 0x0000 for OFF
Multiple coil writes: 1 for ON, 0 for OFF
Address
Description Details
Decimal
Hex
0
0x000
Start/stop manual boost, Default Output
ON to start, OFF to stop
1
0x001
Reset periodic boost charge schedule
ON to reset schedule, OFF is no-op
2
0x002
Start/stop battery check, Default Output
ON to start, OFF to stop
3
0x003
Reset periodic battery check schedule
ON to reset schedule, OFF is no-op
4
0x004
Clear battery check failure, Default Output
ON to reset alarm, OFF is no-op
5
0x005
Clear low cranking failure, Default Output
ON to reset alarm, OFF is no-op
16
0x010
Start/stop manual boost, Channel A
ON to start, OFF to stop
17
0x011
Reset periodic boost charge schedule
ON to reset schedule, OFF is no-op
18
0x012
Start/stop battery check, Channel A
ON to start, OFF to stop
19
0x013
Reset periodic battery check schedule
ON to reset schedule, OFF is no-op
20
0x014
Clear battery check failure, Channel A
ON to reset alarm, OFF is no-op
21
0x015
Clear low cranking failure, Channel A
ON to reset alarm, OFF is no-op
32
0x020
Start/stop manual boost, Channel B
ON to start, OFF to stop
33
0x021
Reset periodic boost charge schedule
ON to reset schedule, OFF is no-op
34
0x022
Start/stop battery check, Channel B
ON to start, OFF to stop
35
0x023
Reset periodic battery check schedule
ON to reset schedule, OFF is no-op
36
0x024
Clear battery check failure, Channel B
ON to reset alarm, OFF is no-op
37
0x025
Clear low cranking failure, Channel B
ON to reset alarm, OFF is no-op
48
0x030
Start/stop manual boost, Channel C
ON to start, OFF to stop
49
0x031
Reset periodic boost charge schedule
ON to reset schedule, OFF is no-op
50
0x032
Start/stop battery check, Channel C
ON to start, OFF to stop
51
0x033
Reset periodic battery check schedule
ON to reset schedule, OFF is no-op
52
0x034
Clear battery check failure, Channel C
ON to reset alarm, OFF is no-op
53
0x035
Clear low cranking failure, Channel C
ON to reset alarm, OFF is no-op
64
0x040
Start/stop manual boost, Channel D
ON to start, OFF to stop
65
0x041
Reset periodic boost charge schedule
ON to reset schedule, OFF is no-op
