Sensitron MULTISCAN++S1 - Diagram and Part Identification

MT3401E.doc rev.0 21/05/13 Pagina 8 di 86
Vac
Power Supply
+
-
BATTERIES
Fig. 2.1 b) Power supply
2.1.1) Diagram and part identification
Box version
1
2
3
8
4
5
6
7
7
1- Power Supply (27 Vdc 4A)
2- 2 x 12V 7Ah batteries (not included)
3- RS232 serial port (PC connection)
4- Parallel port (printer connection)
5- Relay outputs (8)
6- 8 detectors 4-20 mA inputs
7- Bus RS485 bus connections
8- Panel main board
Fig. 2.1.1) Unit diagram and part identification
