2. DEVICE OPERATION MANUAL
Note: The enter key on the remote control has the same functionality as a click of the left mouse button.
2.1 REMOTE KEY INSTRUCTION
2.1.1 REMOTE CONTROL
Handheld Remote Controller Key Functions:
【0－9】keys: During setup, number keys are used to input values. For viewing
channels 1, 2, 3 and 4 use 1, 2, 3 and 4 on numeric keypad respectively.
， : Up, Down directional keys: Move selection up and down in setup
menu.
， : Left, Right directional keys: Move cursor left or right in setup menu.
【QUAD】: Switch to 4 Channel mode.
【FWD】: Fast forward the video while in playback. press【PLAY】to return to
normal speed.
【REV】: Reverse the video while playback, press REW to switch, press
【PLAY】 to return to normal speed.
【POWER ON】: Reset the DVR to Power on and Power off mode. (Standby and Start Up).
【LOGIN/LOCK】: If security is enabled in the setup, use the LOGIN/LOCK key to Login to the DVR and
enter the setup menu. Login by entering the User ID into “User ID select” and Password into the
“Password” input boxes. To exit setup and operation use the lock function.
Note: It is important to remember the password because there is no facility to reset the password.
【OSD】: Press OSD for main menu.
【PTZ】: Not supported.
【EXIT】: Exit to the preview or return to the last menu.
【RECORD】: Start manual record.
【STOP】: Stop manual record.
【ASSISTANT】: (For future use).
5
