Sentry Sample Sequencer 5 User Manual

Sentry Equipment Corp | Sample Sequencer

5
SPD 5.5.15 13
5 OPERATION
To ensure the protection provided by this equipment is not
impaired, this equipment must not be installed or used in any
manner other than that which is specified in this manual.
AVERTISSEMENT
Afin de s’assurer que la protection prévue par cette pièce
d’équipement n’est pas défaillante, cet équipement ne doit
pas être installé ou utilisé de manière autre que spécifié dans
le manuel.
5.1 Description of Controls
The following table and figure describe controls on the Sample Sequencer touch screen display:
Table 1: Control Descriptions
DESCRIPTION FUNCTION
Widgets
Touching a widget will take you to the corresponding function screen
Enter button
Various screens will have an enter button in the lower right corner.
Touching this button will take the value you have entered and update
the previous screen with that value.
Escape button
Various screens will have an escape button in the lower left corner.
Touching this button will return you to the previous screen and any
values will not be saved.
Alpha keypad
Various screens will have an alpha keypad for entering data. Use this
keypad to enter necessary data. Press the Enter button when done
using keypad to return to the previous screen with the data you have
entered.
Numeric keypad
Various screens will have a numeric keypad for entering data. Use this
keypad to enter necessary data. Press the Enter button when done
using keypad to return to the previous screen with the data you have
entered.
Save button
Various screens will have a save button in the lower right corner.
Touching this button will save entered values and return you to the
previous screen.
