Sentry Sample Sequencer 5 User Manual

Sentry Equipment Corp | Sample Sequencer

5
SPD 5.5.15 55
10 SPARE PARTS LIST
Description Sentry P/N
Sample Sequencer board:
Circuit board 4-06084A
Sample Sequencer cable assemblies:
Line power to power supply 2-06933C
12 VDC Power cable 2-06933D
Display cable 4-06140A
Sample Sequencer Enclosure:
Complete Enclosure Assembly 6-04973A
Front Door Assembly 6-04973B
Power Supply 4-05590F
Fuse, 4 A 250 V Fast Acting (for power supply) 4-02055F
Terminal Blocks
12 VDC 4-06084G
Incoming power 4-06084H
Analyzer inputs 4-06084J
Track/Hold, Point indication, Valves 4-06084K
Mounting
Panel Mount gasket 2-06933F
Bolts for mounting 4-06084F
11 ACCESSORIES
Description Sentry P/N
Remote IO Cable, 5 meters 4-06084B
Remote IO Cable, Custom Length 4-06084D
Sentry Manifold Sample Valve (12 VDC) 7-04171A/B
Sentry Back Pressure Regulator (20 psi)/Relief Valve (BPR/RV) 7-00868A
Sentry Flow Indicator with control valve (FICV), 580 cc/min 6-02671D
Sentry Flow Indicator with control valve (FICV), 1600 cc/min 6-02671B
Sentry VREL (Variable Pressure Reducing Element valve) 7-00744A
Filter, 40 Micron, 1/4" Tube Fitting 4-00484K
Replacement Filter Element, 40 mesh 4-00361L
