Dok.-Nr.: D10029.EN Rev.: 11 Page 14 of 30
Manual: Water separator / Fuel pre-filter SWK-2000
Willibrord Lösing
Filterproduktion GmbH
W. Lösing Filterproduktion GmbH • Am Walzwerk 2 • 45527 Hattingen
4.5 Materials used
Filter cover, filter housing
Aluminium
Bowl
Aluminium or transparent PA
Drain valve
Brass, PBT
Gaskets
TPE and/or HNBR
Bleed screw
Steel
Outboard screws
Stainless steel A2
4.6 Electrical data
Electrical components are installed only in conjunction with a filter heater, water in fuel sensor
and/or pressure switch. The electrical data on these options please refer to chaptures 6.1 and 6.2.
Filter sizes for which the above options are available please refer to chapture 4.4.
4.7 Mechanical connections
SWK-2000/5
SWK-2000/10
SWK-2000/18
SWK-2000/40
SWK-2000/130
Fuel inlet
M16x1,5
M22x1,5
M26x1,5
M33x2
G2“
Fuel outlet
M16x1,5
M22x1,5
M26x1,5
M33x2
G2“
Recommended
minimum-diameter
performance
8 mm
12 mm
20 mm
26 mm
40 mm
The dimensions of filter combinations may differ (see Chapter 5)
Adapter for the fuel inlet and fuel outlet can be obtained as an accessory through the W. Lösing
Filtertechnik e. K..
4.8 Temperature ranges
Filters are designed to operate in temperature range of -40 °C to 80 °C.
On the filter with fuel pre heating system, selected thermal fuses are installed. Fuses will be
irrevocably destroyed when ignoring the stated temperature limit.
Filter combinations 5
In some areas of application it may be necessary to combine two structurally identical filters with
one another. Currently, two different combination options are offered.
