Deviations to Chapter 4.2 Dimensions and weights
SWK-
2000/5/U
SWK-
2000/5/50/U
SWK-
2000/10/U
SWK-
2000/18/U
SWK-
2000/40/U
SWK-
2000/130/U
Width [mm]
440
440
460
630
800
1,100
Height [mm]
300
340
380
450
530
860
Depth [mm]
160
160
200
230
280
430
Weight [kg]
< 8
< 8
< 10
< 20
< 40
< 120
Fixing holes
[mm]
2x slotted
holes (18x9)
Distance
apart: 416
2x slotted
holes (18x9)
Distance
apart: 416
4x slotted
holes (18x9)
Distance
apart: 435x85
4x slotted
holes
(24x12)
Distance
apart:
590x80
4x slotted
holes
(24x12)
Distance
apart: 760x100
16x slotted
holes (27x15)
Distance
apart:
See drawings
All sizes and weights may vary according to the precise configuration of the filter assembly. The exact
dimensions should be taken from the specific drawing of your filter.
The performance characteristics from Chapter 4.3 retain their validity for each individual filter.
Deviations to Chapter 4.7 Mechanical connections
SWK-
2000/5/U
SWK-
2000/10/U
SWK-
2000/18/U
SWK-
2000/40/U
SWK-
2000/130/U
Fuel inlet and
outlet
Union nut with a cutting ring for a pipe with an external diameter of
G2“
12 mm
15 mm
22 mm
35 mm
