bag 6
18
CENTRal II aSSEmbly
STEp 24
hIgh TRaCTION CONfIgURaTION lOW TRaCTION CONfIgURaTION
OpTIONal
DEfaUlT
M3X10
M3X10
3x5x2
3x5x2
3x5x2
3x7.5x1
3x7.5x1
3x7.5x1
3x5x2
M3X10
M3X10
3x7.5x1 3x7.5x1
M3x10 M3x10
3x5x2 3x5x2
Recommended for indoor racing and treated
track surfaces (for example sugarwater).
Recommended for general outdoor use
