Serpent F110 SF4 - Rear Assembly

14
REaR aSSEmbly
STEp 18 STEp 19
18.1
18.2
M3x5
M3x6
3x5x2
Pivotball LONG
Pivotball
SHORT
M3x5
M3x8
3x5x1
M3x8
M3x6
M3x6
1
1
2
2
Both bearing holders are not symetrical. Right side one ts a 8mm bore
ballbearing and the left side one ts a 3/8” bore ball bearing.
M3x8M3x5 M3x6
3x5x13x5x2
M3x6
