13
STEp 16 STEp 17
1
2
Pivotball
short
M3x5
M3x6
M3x5
M3x5
M3x5
M3x5
M3x5
M3x5M3x6
4
3
Insert the pod assembly first,
then mount the center pivot
holder. After assembling, adjust
the sidesprings so the pod
plate is preloaded, and perfectly
parallel to the chassisplate.
The carbon plate chamfer must
be oriented to the lowest side
