bag 8
25
ElECTRONICS aSSEmbly
STEp 35
STEp 36
Use double sided tape
to mount the FANS to
the chassis.
M3x6
M3x6
M3x6
Use narrow fans that don’t touch the
pod plate or the battery holder.
