Serpent F110 SF4 - Page 24

24
STEp 32
STEp 33
STEp 34
32.1
34.2
34.1
32.2
1) Fill the shock body with
shock absorber oil. Check
the oil CST value in the setup
sheet.
2) Bleeding: Let the oil settle
and allow the air to escape.
Close the shock slowly.
Important: do not crossthread!
Oil will overow through the
built-in bleed channel.
Tighten carefully until the bottom
half sits against the shock body.
3x5x1
1
2
Insert the o-ring
inside the spring
collar.
3x5x1
