Serpent F110 SF4 - Page 26

26
BATTERYMOUNTPOSITION
STEp 37
hIgh TRaCTION CONfIgURaTION lOW TRaCTION CONfIgURaTION
OpTIONal
DEfaUlT
To assemble the battery it is needed to remove the M3x6 screw and turn the battery holder .
When the battery will be tted assemble the M3x6 screw.
M3x20
M3x20
M3x6
Nylock Nut
M3
M3x6
M3x12
M3x12
M3x6
M3x12
Nylock Nut M3
Recommended for general use. recommended for low traction
use (dusty asphalt, wet racing).
