Serpent F110 SF4 - Page 12

bag 4
12
STEp 14 STEp 15
1
1
2
2
3
4
M3x14
3x6x2.5
M3x5
M3x5
15.1
15.2
M3x14
3x6x2.5 M3x5
To exchange the sidesprings it is needed to remove
before the bearing holder assembled in step 15.1.
To exchange the sidesprings it is needed to remove
before the bearing holder.
