Serpent F110 SF4 - Page 20

20
STEp 26
hIgh TRaCTION CONfIgURaTION lOW TRaCTION CONfIgURaTION
OpTIONal
DEfaUlT
9 mm
STEERINGLINKLENGTH
26.1
26.1
26.2 26.2
M3X6
M3X6
M3X5
M3X5
Check how many teeth your
servo spline has (23, 24 or
25) and use the right levers.
Check how many teeth your
servo spline has (23, 24 or
25) and use the right levers.
M3x6M3x6
24 mm
STEERINGLINKLENGTH
M3x5
M3x5
