22
STEp 29
M3x8
3x5x1
Apply the silicone oil on the inner tube. Use the
silicone oil supplied in the kit. For the correct
cst value please check the default setupsheet.
STEp 28
M3x6
M3x6
M3x6
29.1
29.2
M3x6
M3x8
3x5x1
