STEP 13
REARREACTIVESTEERINGSYSTEM
Serpent 990 introduce the Active rear toe-in. It brings a new dimension to
setup changing the toe-in characteristics of the rear tires under rolling effect.
It allows to run less static toe-in and still have a good traction coming out of
the corner.
Serpent RRS System brings the possibility to adjust the amount of toe-
change over the suspension travel from zero to positive or negative toe-
change depending on the linking point selected as explained below:
Toe in will not change over the
suspension travel.
Toe in will decresase under aceleration
(compression) and will increase under
braking (extension).
Toe in will increase under acel-
eration (compression) and will
decrease under braking (exten-
sion).
2 mm
REARTRACK
WIDTH
M3x8
M3x8
Note the orientation of
the pivot ball as it has a
neck in one side.
