Serpent VIPER 990e - Page 13

bag 4
13
STEP 15
1- Note orientation of the
outside wheel axle shim.
2- Note position of the
lever spring.
12x15x0.25
12x18x1 Conical
12x18x4
M3x4
3x22
12x18x4
12x15x0.25
12x18x4
2.5x12
3x22
1
1
3
4
2
2
2.5x12
15.1 15.2
15.3
M2.5x8
M3x4
M2.5x8
