Connect your headboard to the aachment
plate using the remaining long screws or
hardware that came with your headboard.
The heads of the bolts will face outward. Use
hex key to ghten bolts.
headboard bracket installaon guide (oponal)
STEP 1
STEP 2
STEP 3
a. Align the hole in the bracket to
the brass sleeve into which the
leg threads. Hold the bracket
in place and screw the leg into
the base unl it is snug. DO NOT
OVERTIGHTEN. Too much force
may cause the leg to spin freely.
b. Align the tab with the hole in
the frame (located towards
the foot of the base) and use a
short bolt and nut to secure the
bracket. Make sure the bolt is
ght.
a. Measure the distance between the mounng holes on the
headboard and install the T-Bracket to accommodate the
headboard.
b. To install the T-Bracket, slide the T-Bracket through the end of the
headboard bracket. Align the at side of the T-Bracket plate to the
mounng holes on the headboard.
Aach the plasc spacer and T-Bracket.
Aach the Headboard Bracket.
Headboard Brackets are an oponal accessory and are not included.
A 9/16” & 1/2” socket and crescent wrench are necessary to complete installaon.
c. Secure T-Bracket in place by inserng two short screws through
top of bracket. Use hex key to ghten screws.
