Section 2 Installation Instructions
Part Number 020004000 10/13 2-19
ADA Key Pad Matrix Finish Installation
9. Put the splash panel and merchandiser back onto the
unit and reinstall the screws that hold them in place.
10. Restore power to the unit.
Clean Up
Clean up all work areas. Dispose of all packing material,
excess tubing and trash properly.
12345 678910
12 34
4 Valve Dispensers
12345 678910
123456
6 Valve Dispensers
12345678 910
12345678
8 Valve Dispensers
12345678 910
12345678
8 Valve Dispensers
