Switched PDU
Installation and Operations Manual Installation 17
Ethernet Port
The Switched Cabinet Distribution Unit is equipped with an RJ45 10/100Base-T Ethernet port for attachment to an
existing network. This connection allows access to the Switched PDU via Telnet or Web.
The Switched PDU is configured with the following network defaults to allow unit configuration out-of-the-box
through either Telnet or Web:
NOTE: When installed on a DHCP enabled networks, the following network defaults do not apply because the PDU ships with DHCP
support enabled.
IP address: 192.168.1.254
Subnet Mask: 255.255.255.0
Gateway: 192.168.1.1
The local PC network connection must be configured as noted below:
NOTE: For instructions about reconfiguring the network connection, contact your system administrator. A restart may be required for the
reconfiguration of your network to take effect.
IP address: 192.168.1.x (where x is 2-253)
Subnet Mask: 255.255.255.0
