Switched PDU
Installation and Operations Manual Operations  27
Outlet State/Control State Field Values
Outlet State Control State Description
On On Outlet is on
Off Off Outlet is off
Off Pend On Outlet is off and about to turn on in response to a sequence timer
Off Reboot Outlet is off and a Reboot action has been initiated
On Idle On A restart has occurred – Last Control State has been maintained
Off Idle Off A restart has occurred – Last Control State has been maintained
On Wake On A power-loss has occurred – Wakeup State has been applied
Off Wake Off A power-loss has occurred – Wakeup State has been applied
On/Wait Off Outlet state in transition – Re-query of outlet status required
Off/Wait On Outlet state in transition – Re-query of outlet status required
On/Error varies Error State – Outlet should be off, but current is sensed at the outlet
Off/Error varies Error State – Outlet should be on, but no current is sensed at the outlet
Off/Fuse On Outlet should be on, but a blown fuse has been detected
On/Fuse On Outlet should be on, but a blown fuse has been detected downstream
No Comm varies Communication to the outlet has been lost. Control state will be applied when communication
is re-established.
Power Monitoring
Input Feeds
The Input Feeds page displays:
 The absolute and descriptive names of the infeed
 Infeed status
 Input/branch phase load in amperes
 Input Voltage
 Calculated power usage in Watts.
Monitor pages (like the Input Feeds page) refresh occasionally to reflect current PDU status.
System
The System page displays:
 Calculated power usage for all infeeds in watts
 Configured total system area in square feet
 Calculated power usage in watts/square feet
 Tower monitoring – tower ID, tower name, and tower status
NOTE: For 3-phase systems, if the Out-of-Balance Alerting feature is enabled, and the system goes into a load out-of-balance condition,
the Tower Status field will display the alert “3ph Out-of-Balance”, unless there is a higher priority tower error state to report.
Monitor pages (like the System page) refresh occasionally to reflect current PDU status.
UPS
The UPS page displays the following information for each UPS device associated with the unit:
 Status
 Voltage
 Hostname/IP address
NOTE: The UPS page displays both IPv4 and IPv6 formats in the Hostname/IP field.
Monitor pages (like the UPS page) refresh occasionally to reflect current PDU status.
