Working with the crane
unbalanced
There is a risk of not being able to control the movement of the
crane. Balance the crane before operating it.
The steel side cables are
broken
There will be no control of the next section, it will be detached from
the system and therefore uncontrollable. The crane cannot work
until the cables have been replaced.
The main section belt
moving the first section
breaks
If the crane is in the horizontal position no risk will happen. If the
crane is tilted, even slightly, the counterweights trolley will move
freely, and the balance of the crane will be lost. The crane cannot
work until the belt has been replaced.
Moving the telescopic arm
with something blocking it
There is a risk to burn the motor or damage some mechanical
component. Remove anything blocking the telescopic section
before operating the crane.
One guiding wheel breaks
or is too tight
The rail can be damage and the movement of the crane is not
smooth. Replace/readjust the wheel.
The arm motor belt is
broken
If the crane is in the horizontal position no risk will happen. If the
crane is tilted and not balanced, the CWE trolley will move freely,
and the balance of the crane will be lost. The crane cannot work
until the belt has been replaced.
Pan or Tilt brake pads
loose
The crane will be moved freely by the wind and it can hit anything
in the surroundings.
The crane will stop but there are no risks associated. Replace the
electronic Box to operate the crane again.
There will be no correction of the horizon and the balance of the arm
when it is tilted will be lost. Replace the leveling head.
Working in Electrical
storm conditions (lighting
and thunderstorms)
There is the risk of serious injury and death by electrocution or burns
for the operators/technicians or any personnel near the crane.
The consequences of ignoring the maximum wind speeds permitted
to operate each Scorpio crane will lead into overturning/capsize.
With a REAL RISK of injuring crew and personnel around the
camera car.
5.3 POTENTIAL DANGERS FOR THE USER
There are mechanical dangers to behold, but if the crane is manipulated with all protections,
equipment covers and instructions received under both the user’s manual and the training given
by Servicevision’s authorized trainee, it should be no danger.
Noteworthy, the operators must always know the performance limits of the machine, thus watching
that no person entering the physical space of operation. In locations where there is presence of public,
it also must perform a hazard warning verbally or implement a security fence to prevent any approach.
Operators will also be responsible for monitoring during the operation; no person may come into
contact with the crane:
