SCORPIO LIGHT SERIES 10’/17’/23’L - TECHNICAL INFORMATION - Basic information
Version 1.04 May 26, 2022
SERVICEVISION BIS SL
Ríos Rosas, 20 · 08940 CORNELLA DE LLOBREGAT (Barcelona) Spain · Tel. 34 93 223 86 30 · Fax 34 93 223 86 31 7
comercial@servicevision.es · www.servicevision.es
1 TECHNICAL INFORMATION
1.1 BASIC INFORMATION
Servicevision provides a completely new concept of telescopic arms to the film and television
industry. The Scorpio light series cranes had been designed to be the swiss army knife of the camera
support equipment. Bringing a new whole and never-ending full range of possibilities and solutions
on the remote camera support.
Another revolutionary feature of the light series is the possibility of displaying whole movement
manually. In manual mode, the director, the photographer, or camera operator will manually perform
the pan, tilt, and telescopic movement of the crane while the arm remains balanced, and the head
levelled to horizon…. as said, a new whole world of possibilities.
The Electronic box to control the crane is extra small and light comparing to the heavy-duty series.
With a removable touch panel display, it keeps all the functions and features developed by Scorpio
for its bigger brothers. The arc compensator, operational limits, selectable speeds, memorization and,
of course, interfaceable with the Scorpio heads to perform back pan and targeting functions.
SCORPIO 10’
THE UNIQUE ALL TERRAIN PORTABLE TELESCOPIC ARM IN THE MARKET.
Mitchel mounted in its Fulcrum; the arm it is compatible with any dolly in the market. Very compact
when retracted and light to make it very easy to move and maneuver when accessing to difficult and
small locations. A main tube plus two telescopic sections give 2.3 mts of telescopic travelling. With a
60kg payload capacity the Scorpio 10’ is robust providing a solid and smooth continuous camera
movement.
The Scorpio 10’ can be provided together Scorpio Dolly. As robust and light as the arm, designed
to be the perfect carrier for either the Scorpio 10, the Scorpio 17’ and Scorpio 23’L. The articulable
arms give the capacity of changing its width in three different positions: for 0.62mts standard dolly
tracks, for 0.41mts tracks, and the last and narrowest configuration of only 0.65 total width, to make
this telescopic arm + dolly accessible almost anywhere (this smallest configuration is not for
operational mode).
Another key component is the telescopic column provided with the Scorpio Dolly. One single
telescopic section, both manually or drill operated and as well as the Scorpio Dolly, the column has
been designed to operate either the Scorpio 10’, 17’ and 23’L arms. Rise the column and reach the
maximum tilt angle and optical height or low down the column and you will be able to get through any
doorway higher than 173cm.
The Scorpio Dolly and the column are optional accessories when purchasing the Scorpio 10’ and
included when purchasing the Scorpio 17’ or 23’L.
