SCORPIO LIGHT SERIES 10’/17’/23’L - TECHNICAL INFORMATION - Basic information
Version 1.04 May 26, 2022
8
SCORPIO 17’
THE MIDDLE RANGE LIGHT COMPACT TELESCOPIC CRANE...
Mitchell mounted Fulcrum and with a main arm section with 3 telescopic sections, instead of 2, It
keeps the advantages and characteristics of the Scorpio 10’ but reaching a longer range of 4.05mts
and keeping it in the light and compact crane concept, not affecting the portability and mobility. Using
the very same Scorpio dolly as the Scorpio 10’ warranties flexibility and accessibility to any location.
As well as the Scorpio 10 and Scorpio 23’L, the 17’ belongs to the light line of cranes for Scorpio,
where the arm can be removed very easy and quick, without the need of lifting or towing machine,
only between 2- and 4-men operation can remove, assemble, and transport any of the arms (10’, 17’
and 23’L). The Michell mounted fulcrum allows to mount it in any Mitchell mount support and all the
light series cranes range (Scorpio 10, 17 and 23’L) it gives the possibility of splitting the system in
three separate operational parts, arm and fulcrum, the dolly and the column.
With the same payload capacity (60kgs.), it is the good match to be used in a vehicle, it is also a
versatile small telescopic crane for any shooting situations such as stages, studios, small locations…
a good solution for any job.
SCORPIO 23’L
THE LONGEST RANGE WITH THE LIGHTEST WEIGHT…
This crane is designed to reach up to 5.6meters of telescopic range for a little bit less of payload
capacity. The 40kgs payload warranties the capacity of taking any two axis or small stabilized remote
head in the market with it and be able to reach 23 feet with a very light arm. Following the concept of
the light series, the 23’L crane is also Mitchel mounted fulcrum and it consist in a main tube with 3
telescopic sections, like the Scorpio17 and keeping the concept of compatibility, maneuverability and
portability of these light series.
In comparation to the regular Scorpio23’, this crane has the same length but much lighter and
maneuverable. Mounted in the Scorpio Dolly gives this extra plus in maneuverability and accessibility
to small or difficult access locations. And because is mounted in the same telescopic column allows
to get a 23’ telescopic crane fully mounted and loaded through any doorway.
