Installation Instruction
9
According to the type of support, all or only some of the slots on the box are used (Fig.13).
To prevent vibrations or noise during use, make sure that there is a solid fixture every 600 mm and that the box is fas-
tened with the slots closest to the two heads.
WARNING
Before completely tightening the screws, make sure that the girder is “level” in both the length and depth directions
(Fig.14). Positioning errors over the angles indicated in the figure compromise automatism operations.
Fig. 14
LIGHT MILLENNIUM
Fig. 13
