12.0 Specications continued
13.0 Panel mount instructions
Adjustment capabilities (accessible through the user set-up menus)
Voltage inputs +11 to -11 volts
Current inputs 0 to 20 mA
Maximum reading +31999
Minimum reading -9999
Input specications
Transmitter input signal 4-20 mA
Transmitter input impedance 150 ohm
Transmitter input voltage drop 3 VDC (max.)
Transducer input signal +11 VDC to -11 VDC
Transducer input impedance 45K ohm
1. Slide the panel mount tab with screw into slot
on the side of the meter as shown.
