Bases Setup • Super II 67
Soft Key:
ADDRESS
Changing the Address of a Single Base
The Super II controller is capable of communicating with up to eight separate bases. Each base on the
scale network must have a unique address from 1 to 8. As a default, all bases come from the factory set to
address 1. Additionally, the Remote Scale Option circuit boards for strain guage load cell remote bases
come from the factory set to address 2. To access additional Setra or strain gauge load cell bases or to
rename the current Setra or strain gauge load cell base, please follow the procedure below.
To access the ADDRESS changes in the Bases Setup menu, follow the menu tree or press the keys in the
order listed below.
Press the ADDRESS soft key.
To add any additional bases beyond the standard Base 1 and Base 2 selections, or to reassign the address
of existing bases, follow the procedure below:
1. Attach the Setra base to be reassigned directly to the controller.
2. Apply power to the base.
3. After scale countdown, the base will appear as Base 1 (or another number if it has already been reassigned).
4. Access the Bases Setup menu by following the above procedure.
5. Press the ADDRESS soft key.
6. A menu will appear showing all eight possible base selections and the names associated with each base number.
SETUPS
MORE
BASES
SETUP
MORE
abc reset
tare
menu remote
ADDRESS
GO BACK
Select the base to reassign:
1. Base 1 5. Base 5
2. Base 2 6. Base 6
3. Base 3 7. Base 7
4. Base 4 8. Base 8
