Turn on Settop M1
When you received SETTOP M1 for the first time, it is necessary to set a minimum setting. You can follow
this setting Step by Step:
Configuring via Wi-Fi
•
Step 1:
Connect Power Cable (Ref. 310508) in COM 1 or COM2, or internal battery (Ref. M1-Rover-Battery)
•
Step 2:
Press the ON/OFF button and wait until the OS Boots Up. Wi-Fi LED flashes modulate (see diagram in
section 1.4 Settop M1 Scheme) when searching for a network and Wi-Fi LED flash 2 times per second when
it is in adhoc mode. If the receiver has been misconfigured and wants to reconfigure in ad-hoc mode, you
must press the ON/OFF button for 3 times.
•
Step 3:
With a PC, iPhone or iPad with Wi-Fi Access, press “search network”. It will appear as one network called
“Settop M1 SN” (SN is a serial number).
•
Step 4:
Enter Network password “adhoc”.
•
Step 5:
Open your Internet browser (it supports Google Chrome and Safari) and key in IP address 192.168.2.2
•
Step 6:
 User name is: admin
 Password: m1
Configuring via PHONE
•
Step 1:
Connect Power Cable (Ref. 310508) in COM 1 or COM2, or internal battery (Ref. M1-Rover-Battery)
•
Step 2:
Press the ON/OFF button and wait until the OS Boots Up. Phone LED flashes constantly (one or two times
per second) (see diagram in section 1.4 Settop M1 Scheme).
•
Step 3:
With a PC, iPhone or iPad, open your Internet browser (it supports Google Chrome and Safari) and key in
static IP address assigned at SIM card.
•
Step 4:
 User name is: admin
 Password: m1
NOTE: If you use a Windows 8.1, you need to configure your operating system (see FAQ - I use
Windows 8.1, can I connect with Settop M1? )
