COMMUNICATIONS
Radio Module
•
Bandwidth:
 390 - 430 MHz or
 430 - 470 MHz
•
Frequency Control
•
Synthesized 12.5 kHz resolution setting
•
Frequency Stability ± 1 ppm
•
12.5/25 kHz Channel Spacing (detectable)
•
RF Transmitter Output
•
w (RX-only) & 0.1-1 w (Programmable)
•
Sensibility:
 -110 dBm VER = 1 x 10-5
•
Adjacent Channel Sensitivity:
 55 dB
•
Certification type
All models are accepted and certified to operate in the U.S., Australia and Canada FCC, IC, EU, NZ,
Australia ETS300-113-2
GSM HSDPA modem (3,5G)
Option A
•
Dual Band UMTS: 900 / 2100 MHz (EU3-E)
•
Tri-Band UMTS: 850 / 900 / 2100 MHz (EU3-P)
•
Dual Band GSM: 900 / 1800 MHz
•
HSDPA data: DL : max. 3.6 Mbps, UL: max. 384 kbps
•
UMTS data: DL: max. 384 kbps, UL: max. 384 kbps
•
EDGE data: DL: max. 237 kbps, UL: max. 118 kbps
•
GPRS data: DL: max. 86 kbps, UL: max. 43 kbps
•
GSM/CSD data transmission: 14.4 kbps
Option B
•
Five-Bands UMTS/HSPA+ (WCDMA/FDD) (800/850/900/1900/2100 MHz)
•
Quad-Band GSM (850/900/1800/1900 MHz)
•
HSDPA Cat.10 / HSUPA Cat.6 data rates DL: max. 14.4 Mbps, UL: max. 5.76 Mbps
•
EDGE Class 12 data rates DL: max. 237 kbps, UL: max. 237 kbps
•
GPRS Class 12 data rates DL: max. 85.6 kbps, UL: max. 85.6 kbps
•
CSD data transmission 14.4 kbps, V.110
Wi-Fi
•
IEEE 802.11b/g
Bluetooth
•
2.0 + ERD (Enhanced Data Rate) wireless technology.
COMMUNICATION PORTS
•
1 RS232/USB Host Event port, PPS Power In/Out
•
2 RS232/USB OTG port Power In/Out
•
1 TNC connector for GPS antenna
•
1 TNC connector for radio antenna
•
1 FME connector for GSM antenna
•
1 Slot SIM card
•
1 Slot MicroSD card
