Settop M1 - Back View Connections

SETTOPSURVEY, S.L. Bofarull 14, 08027 Barcelona (Spain) Phone: (+34) 93 340 05 73 Fax: (+34) 93 351 95 18 www.settopsurvey.com info@settopsurvey.com
12
Back View
Radio
Radio antenna connector
COM1
Lemo connector for RS232/ power in
COM2
Lemo connector for USB / power in/out (RS232 with adapter cable)
Phone
GSM Antenna connector
Satellites
GPS Antenna connector
