Constant flashing
(3 per second)
Station connected via cable and bluetooth
USB - RS232
USB (Green LED)
Status
Action
Turned Off Device Disconnected
Constant flashing
(2 per second)
Device connected via USB in LEMO 2
RS232 (Red LED)
Status
Action
Turned Off Device disconnected
Constant flashing
(1 per second)
Device connected via RS232 in LEMO1
Constant flashing
(2 per second)
Device connected via RS232 in LEMO2
Constant flashing
(3 per second)
Device connected via RS232 in LEMO1 and
LEMO 2
Constant flashing
(1 Hz)
Service mode
