10
Flashing light Linking to a device
Fixed Device linked
Wi-Fi (Red LED)
Status
Action
Turned Off Not linked to any network
Modulated light Looking for a network Wi-Fi
Constant flashing
(2 per second)
AD-HOC Mode
Fixed Network linked
Radio - Phone
Radio (Green LED)
Status
Action
Turned Off Doesn’t use radio
Constant flashing
(1 per second)
Radio signal transmitting (e.g. Mode Base)
Constant flashing
(2 per second)
Radio signal receiving (e.g. Mode Rover)
Phone (Red LED)
Status
Action
Turned Off Doesn’t use phone
Fixed Doesn’t have SIM CARD
Constant flashing
(1 per second)
GPRS Coverage
Constant flashing
(2 per second)
HSDPA Coverage
Constant rapid
flashing
Error
Satellites - External devices
Satellites (Green LED)
Status
Action
Turned Off Not receiving Satellites
Flashing “n”
constant flashes
Receiving “n” Satellites
Constant rapid
flashing
Error
External devices (Red LED)
Status
Action
Turned Off Device not linked
Constant flashing
(1 per second)
Total Station linked via USB
Constant flashing
(2 per second)
Total Station linked via bluetooth
