8.5.1.4 - Standby values
This menu is used to set the parameters which must be sent to the fixtures when they are not
involved in a scene or used manually.
It’s very important to set these values, particularly when operating with fixtures fitted with
discharge lamps, whose shutters have to be closed to avoid unwanted illumination, or for those
with halogen lamps, for which, as well as closing the shutter, output can be lowered by dimming
the light. The menu is the following:
. Press the right-hand arrow
to access setting and the left-hand button to exit the function.
Once OK (right-hand SCROLL) has been pressed, the effect string created in 8.5.1.2 will reappear:
the following menu appears:
. Use the CURSOR up/down
arrows to set the value, left/right to pass from effect to effect, press the right-hand SCROLL to go
to page 2 and the left-hand SCROLL to return to the previous menu.
In this case: and then
.
These settings therefore indicate that when the scanner is not being used the dimmer must be at
0 and the shutter closed.
Press the dark grey button corresponding to the string on the display: it’s possible to set an
“indeterminate” condition, i.e. the value “none” corresponding to three dashes (—-).
Press the left-hand SCROLL to return to the creation menu now. Storage is automatic.
8.5.1.5 - Type of effect
This menu is used to decide which of the new fixture’s functions are effects and which are dim-
mers. Dimmer functions will always be subjected to the action of the fader: this allows a program
assigned to a Memory Register to “come up” gradually, along with the other luminaires controlled
by the desk. The menu is the following:
. Press the right-hand arrow
to access setting and the left-hand button to exit the function.
Once OK (right-hand SCROLL) has been pressed, the effect string created in 8.5.1.2 reappears
and the following menu appears:
. Use the CURSOR up/down
arrows to set the value, left/right to pass from effect to effect, press the right-hand SCROLL to go
to page 2 and the left-hand SCROLL to return to the previous menu.
DIMMR COLOR PALET GOBOS ROT.G SHUTR <->
[EFF] EFF EFF EFF EFF EFF P1
Select feature to configure for esc<-
NNNNNNNNNNNN--[EFFECTS TYPE ] ok->
PRISM ----------------------------- <->
[---] --- --- --- --- --- P2
DIMMR COLOR PALET GOBOS ROT.G SHUTR <->
[000] --- --- --- --- 000 P1
DIMMR COLOR PALET GOBOS ROT.G SHUTR <->
[ -] -- -- -- -- -- P1
Select feature to configure for esc<-
NNNNNNNNNNNN--[STAND-BY VALUES ] ok->
