appendice
page 45
I D F E
• Setting Beam Search values, of no use with this unit:
• Setting the control of the parameters for the channels (Linear or Tabular), in which there is only
the Linear value, as the two channels have continuous regulation:
This setting finishes the procedure for creating multiple units.
Working in this way means that operators can also create multiple colourchangers, for example
by setting 5 SGM Colorbasic 250 fixtures (which require 5 channels each) in a single unit. In this
case, addressing must be in blocks of five.
11.2 - Multiple scanner units
Scanners (or moving head fixtures) have 4 channels reserved for control of the moving parts (see
parag. 8.5.1.6).
When creating a multiple unit, it’s impossible to assign more than one channel to movement con-
DIM13 RAT13 DIM14 RAT14 DIM15 RAT15 <->
[LIN] LIN LIN LIN LIN LIN P5
DIM10 RAT10 DIM11 RAT11 DIM12 RAT12 <->
[LIN] LIN LIN LIN LIN LIN P4
DIM07 RAT07 DIM08 RAT08 DIM09 RAT09 <->
[LIN] LIN LIN LIN LIN LIN P3
DIM04 RAT04 DIM05 RAT05 DIM06 RAT06 <->
[LIN] LIN LIN LIN LIN LIN P2
DIM01 RAT01 DIM02 RAT02 DIM03 RAT03 <->
[LIN] LIN LIN LIN LIN LIN P1
DIM13 RAT13 DIM14 RAT14 DIM15 RAT15 <->
[ --] -- -- -- -- -- P5
DIM10 RAT10 DIM11 RAT11 DIM12 RAT12 <->
[ --] -- -- -- -- -- P4
DIM07 RAT07 DIM08 RAT08 DIM09 RAT09 <->
[ --] -- -- -- -- -- P3
DIM04 RAT04 DIM05 RAT05 DIM06 RAT06 <->
[ --] -- -- -- -- -- P2
DIM01 RAT01 DIM02 RAT02 DIM03 RAT03 <->
[ --] -- -- -- -- -- P1
ENTER THE DIP-SWITCH CONFIGURATION
n.dip=[--] 1st channel = - ok->
