page 44
• Setting for Mirror/Head (the fixture has no moving parts):
• Setting for Slope Speed, done bearing in mind that both the dimmer and the Flasher DMX 1.5
flash rate have linear regulation:
• Setting for the new fixture’s name:
• Setting for remote reset and lamp ignition (not available on the Flasher):
• Choosing the setting modes, i.e. the way in which the start address has to be calculated. On a
Flasher DMX 1.5, the setting is done using rotary switches that indicate the address in decimal
numbers, so this setting is useless:
RESET OFF ON ≥ LAMP OFF ON
[--] --- --- ≥ -- --- --- ok->
ENTER/MODIFY THE NAME OF THE UNIT
-SuperFlasher-
DIM13 RAT13 DIM14 RAT14 DIM15 RAT15 <->
[SOFT] SOFT SOFT SOFT SOFT SOFT P5
DIM10 RAT10 DIM11 RAT11 DIM12 RAT12 <->
[SOFT] SOFT SOFT SOFT SOFT SOFT P4
DIM07 RAT07 DIM08 RAT08 DIM09 RAT09 <->
[SOFT] SOFT SOFT SOFT SOFT SOFT P3
DIM04 RAT04 DIM05 RAT05 DIM06 RAT06 <->
[SOFT] SOFT SOFT SOFT SOFT SOFT P2
DIM01 RAT01 DIM02 RAT02 DIM03 RAT03 <->
[SOFT] SOFT SOFT SOFT SOFT SOFT P1
X(PAN) ≥ Y(TILT) ≥ MIRROR/HEAD
H[--]L -- ≥H -- L -- ≥ OUTPUT ok->
DIM13 RAT13 DIM14 RAT14 DIM15 RAT15 <->
[DIM] EFF DIM EFF DIM EFF P5
DIM10 RAT10 DIM11 RAT11 DIM12 RAT12 <->
[DIM] EFF DIM EFF DIM EFF P4
DIM07 RAT07 DIM08 RAT08 DIM09 RAT09 <->
[DIM] EFF DIM EFF DIM EFF P3
